5.4 16×digital input
The module 16×digital input detects the binary control signals of the process level
and transfers them to the master bus system.
Note!
The chapter ”Parameter setting” describes how to parameterise
the module.
z
16 digital inputs
z
Suitable for switches and proximity switches
z
LED displays the states of the digital inputs
0
1
epm-t129
Fig. 5.4-1 Overview of 16×digital input
LED for status display
Plug-in terminal strip
Description
Features
Overview
