Lenze EPM-T110 - Fig. 9.4-2 Data Transmission between IO System IP20 and Controller

Transmitting process data
Data transmission between I/O system IP20 and controller
9
Networking via system bus (CAN)
9.4
9.4.8
l
9.4-11
EDSPM-TXXX-3.0-04/2004
9.4.8 Data transmission between I/O system IP20 and controller
z The basic identifiers of PDO1-Rx and PDO1-Tx are pre-assigned in such a
way that they can exchange data with the process data objects of
CAN-IN3/OUT3 of a controller.
z The basic identifiers of PDO2-Rx and PDO2-Tx are pre-assigned in such a
way that they can exchange data with the process data objects of
CAN-IN2/OUT2 of a controller.
l
L
EPM – T110 1A.10
PW
ER
RD
BA
ADR.
0
1
+
–
DC
24V
X1
DO 8xDC24V 1A
.0
L+
.1
.2
.3
.4
.5
.6
.7
F
1
2
3
4
5
6
7
8
9
L
10
EPM – T220 1A
DI 8xDC24V
.0
.1
.2
.3
.4
.5
.6
.7
1
2
3
4
5
6
7
8
9
L
10
EPM – T210 1A
PDO1-Rx
CAN_OUT3
CAN_IN3
PDO1-Tx
0
1




epm-t112
Fig. 9.4-2 Data transmission between I/O system IP20 and controller
PDO-Rx The I/O system IP20 receives the status information of the controller
PDO-Tx The I/O system IP20 transmits the status information to the controller

Controller with node address 1 (C0350 = 1)
c 768
d
(Basic identifier) + 1 (node address) = 769
d
(identifier)
d 769
d
(Basic identifier) + 1 (node address) = 770
d
(identifier)

CAN gateway of the modular system (or a module of the compact system)
with node address 2
e 767
d
(Basic identifier) + 2 (node address) = 769
d
(identifier)
f 768
d
(Basic identifier) + 2 (node address) = 770
d
(identifier)
