Transmitting process data
Compatibility with Lenze drive and automation components
9
Networking via system bus (CAN)
9.4
9.4.7
l
9.4-10
EDSPM-TXXX-3.0-04/2004
A control task requires the connection of 4 digital outputs, 10 digital inputs and
3 analog outputs to an 8200 vector frequency inverter.
The planned solution is a modular system with the following modules:
I/O system IP20 Number
Required PDOs
I
/
O
s
y
s
t
e
m
I
P
2
0
Modular system
N
u
m
b
e
r
modules
PDO-Rx PDO-Tx
8×digital input / output 1 1/8 1/8
8×digital input 1 – 1/8
4×analog input 1 1 –
Sum 3 9/8 2/8
For exchanging the process data, the 8200 vector makes enough PDOs available:
Frequency inverter
Available PDOs
F
r
e
q
u
e
n
c
y
i
n
v
e
r
t
e
r
PDO-Rx PDO-Tx
8200 vector 2 2
Example
Solution
