1×counter/16×digital input
5
The modular system
5.15
l
5.15-1
EDSPM-TXXX-3.0-04/2004
5.15 1×counter/16×digital input
The module 1×counter/16×digital input detects the binary control signals of the
process level and transfers them to the master bus system. In addition, a counter
canbetriggeredviathefirsttwoinputs.
Note!
The chapter ”Parameter setting” describes how to parameterise
the module.
z
16 digital inputs
z
Adjustable counter function (pulse, frequency) for the first two inputs
z
Suitable for switches and proximity switches
z
LED displays the states of the digital inputs
0
1
epm-t129
Fig. 5.15-1 Overview of 1×counter/16×digital input
LED for status display
Plug-in terminal strip
Description
Features
Overview
