Lenze EPM-T110 - Status of the Digital Inputs; Status of the Digital Outputs

Diagnostics
Status of the digital inputs
9
Networking via system bus (CAN)
9.11
9.11.4
l
9.11-4
EDSPM-TXXX-3.0-04/2004
9.11.4 Status of the digital inputs
Via the index I6000
h
the status of the digital inputs can be displayed.
Index Name Possible settings Important
Lenze Selection
I6000
h
Digital input 0 {1} 255
Display only E 9.11-4
1 Module 1
p
y
y
digital input status
2 Module 2
... ...
32 Module 32
9.11.5 Status of the digital outputs
Via the index I6200
h
the status of the digital outputs can be displayed:
Index Name Possible settings Important
Lenze Selection
I6200
h
Digital output 0 {1} 255
Display only E 9.11-4
1 Module 1
p
y
y
digital output status
2 Module 2
... ...
32 Module 32
