Commissioning examples
I/O system IP20 at the 93xx controller
11
Commissioning
11.3
11.3.1
l
11.3-4
EDSPM-TXXX-3.0-04/2004
When using the communication profile CANopen
1. Adapt the basic identifiers for the process data object 1.
– Set PDO1-Rx via index 1400
h
, and subindex 1 to 770.
– Set PDO1-Tx via index 1800
h
, and subindex 1 to 769.
2. Make a ”reset node” by setting the index I2358
h
= 1. The settings are
accepted.
Setting of the baud rate and node address:
CANopen Baud rate
Coding switch value [kbit/s]
80 1000
81 500
82 250
83 125
84 100
85 50
86 20
87 10
88 800
Bold print = Lenze setting
1. Switch the CAN gateway module voltage supply off.
2. Use the coding switch to set the required baud rate.
– Select value 91.
3. Switch the CAN gateway module voltage supply on.
– The LEDs ER, RD and BA are blinking with a frequency of 1 Hz.
4. LEDs ER and BA go off after 5 seconds, and the set baud rate is stored.
5. Now set the node address 2 with the coding switch.
6. The set node address will be accepted after 5 seconds.
– LEDRDgoesoff.
– The CAN gateway module changes to Pre-Operational status.
Note!
The node address can be changed any time with the coding
switch. The setting is accepted after switching on the supply
voltage.
