Parameterising analog modules
Signal functions of 4xanalog output
12
Parameter setting
12.3
12.3.5
l
12.3-12
EDSPM-TXXX-3.0-04/2004
Parameter
bytes
2/3/4/5
Tolerance
2)
Format
1)
Signal rangeSignal function
06
h
Current signal output 0 ... 20 mA
0
0
{0.01 mA}
{1
dec
}
+20.00
16384
±0.2 %
Lower range limit: –
B
Upper range limit: +23.70 mA
+20480
dec
B
0Bh Current si gnal output ±20 mA
-20.00
-27648
{0.01 mA}
{1
dec
}
+20.00
27648
±0.05 %
Lower range limit: -23.70 mA
-32767
dec
A
Upper range limit: +23.70 mA
+32767
dec
0C
h
Current signal output 4 ... 20 mA
4.00
0
{0.01 mA}
{1
dec
}
20.00
27648
±0.05 %
Lower range limit: 0mA
-5530
dec
A
Upper range limit: +22.96 mA
+32767
dec
0E
h
Current signal output 0 ... 20 mA
0
0
{0.01 mA}
{1
dec
}
20.00
27648
±0.2 %
Lower range limit: –
A
Upper range limit: +22.96 mA
+32767
dec
A
1)
Format of the o utput data (Q 12.3-7).
2)
The tolerance values were detected at an ambient temperature of 25 °C and 15 conversions/s. The values refer
to the final value.
