1×counter/16×digital input
5
The modular system
5.15
l
5.15-3
EDSPM-TXXX-3.0-04/2004
Type
1×counter/16×digital input
Voltage supply DC 5 V / 100 mA (via backplane bus)
Connectable cable cross-section ≤ 1.5 mm
2
(≥ AWG 16)
Digital inputs
Rated input voltage DC 24 V (DC 18 ... 28.8 V)
Number of i nputs 16
Level LOW: DC 0 ... 5 V
HIGH: DC 15 ... 28.8 V
Input current 7mA
Input resistance 3.3 kΩ
Delay time 3ms
Delay - pulse input 100 µs
Counter
Number 1
Inputs 2
Max. frequency 100 kHz
Electrical isolation from the backplane bus Yes, via optoc ouplers
Communication
Input data 6bytes
Output data 6bytes
Parameter data 1byte
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 50 g
Order designation EPM-T430
Technical data
