Lenze L-force 8400 BaseLine D - Page 151

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 151
8400 BaseLine D | Software Manual
Function library
Function blocks
Parameter
Identifier/data type
Index
Possible settings INFO
dnActRetain
DINT
Saves the current setpoint
nHighLimit
C800
INT
-199.9 % 199.9 Upper limit
• Initialisation: 100.0 %
nLowLimit
C801
INT
-199.9 % 199.9 Lower limit
•Initialisation: -100.0 %
wTir
C802
WORD
1 0.1 s 6000 Acceleration time - main setpoint
(Tir)
• 10 ≡ 1 s
• Initialisation: 10 s
wTif
C803
WORD
1 0.1 s 6000 Deceleration time Tif
• 10 ≡ 1 s
• Initialisation: 10 s
Function
C804
BYTE
Function selection
•Initialisation: 0
0No further action; nOut_a retains its
value.
1 The motor potentiometer returns to
0 % with the deceleration time Tif.
2 The motor potentiometer runs to
the lower limit value with the
deceleration time Tif (nLowLimit)
3 The motor potentiometer output
immediately changes to 0 %
Important for the emergency stop
function
4 The motor potentiometer output
immediately changes to the lower
limit value (nLowLimit)
5 The motor potentiometer runs to
the upper limit value with the
acceleration time Tir (nHighLimit)
byInitFunction
C805
BYTE
Behaviour after mains power-up
•Initialisation: 0
0 The output value being output
during mains power-up, is saved
non-volatilely in the internal
memory of the controller. It will be
reloaded during mains power-up.
1 The lower limit (nLowLimit) is loaded
during mains power-up.
2 An output value = 0 % is loaded
during mains power-up.
