Lenze L-force 8400 BaseLine D - Page 199

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 199
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00222
C00222
C00223
C00224
C00225
C00226
C00227
Parameter | Name:
C00222 | L_PCTRL_1: Vp
Data type: INTEGER_16
Index: 24353
d
= 5F21
h
From version 03.00.00
FB L_PCTRL_1
: Gain factor Vp for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.1 500.0 1.0
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00223 | L_PCTRL_1: Tn
Data type: UNSIGNED_16
Index: 24352
d
= 5F20
h
From version 03.00.00
FB L_PCTRL_1
: Reset time Tr for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
20 ms 6000 400 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00224 | L_PCTRL_1: Kd
Data type: UNSIGNED_16
Index: 24351
d
= 5F1F
h
From version 03.00.00
FB L_PCTRL_1
: Derivative-action coefficient Kd for the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 5.0 0.0
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00225 | L_PCTRL_1: MaxLimit
Data type: INTEGER_16
Index: 24350
d
= 5F1E
h
From version 03.00.00
FB L_PCTRL_1
: Maximum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 199.9 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00226 | L_PCTRL_1: MinLimit
Data type: INTEGER_16
Index: 24349
d
= 5F1D
h
From version 03.00.00
FB L_PCTRL_1
: Minimum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 -199.9 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00227 | L_PCTRL_1: acceleration time
Data type: UNSIGNED_32
Index: 24348
d
= 5F1C
h
From version 03.00.00
FB L_PCTRL_1
: Acceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.0 s 999.9 0.1 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
