Lenze L-force 8400 BaseLine D - Page 202

8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00443
202 L Firmware 03.00 - DMS EN 5.0 - 07/2009
C00443
Parameter | Name:
C00443 | DIx: Level
Data type: UNSIGNED_16
Index: 24132
d
= 5E44
h
Bit coded display of the level of the digital inputs
I/O terminals
Display range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 DI1 Bit set = HIGH level
Bit 1 DI2
Bit 2 DI3
Bit 3 DI4
Bit 4 Reserve
Bit 5 Reserve
Bit 6 Reserve
Bit 7 Reserve
Bit 8 Reserve
Bit 9 Reserve
Bit 10 Reserve
Bit 11 Reserve
Bit 12 Reserve
Bit 13 Reserve
Bit 14 Reserve
Bit 15 CINH
Subcodes Info
C00443/1 DIx: Terminal level
C00443/2 DIx: Output level
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT
