166–168 error messages
166.80 The motor (tray 2 pass-through) did not turn on. See “Motor (tray [x] transport) failure service
check” on page 198.
166.81 The motor (tray 2 pass-through) did not turn o.
166.82 The motor (tray 2 pass-through) speed did not
ramp up to the required level.
166.83 The motor (tray 2 pass-through) stalled.
166.84 The motor (tray 2 pass-through) ran too slow.
166.85 The motor (tray 2 pass-through) ran too fast.
166.86 The motor (tray 2 pass-through) did not run at the
correct timing.
167.80 The motor (tray 3 pass-through) did not turn on.
167.81 The motor (tray 3 pass-through) did not turn o.
167.82 The motor (tray 3 pass-through) speed did not
ramp up to the required level.
167.83 The motor (tray 3 pass-through) stalled.
167.84 The motor (tray 3 pass-through) ran too slow.
167.85 The motor (tray 3 pass-through) ran too fast.
167.86 The motor (tray 3 pass-through) did not run at the
correct timing.
168.80 The motor (tray 4 pass-through) did not turn on.
168.81 The motor (tray 4 pass-through) did not turn o.
168.82 The motor (tray 4 pass-through) speed did not
ramp up to the required level.
168.83 The motor (tray 4 pass-through) stalled.
168.84 The motor (tray 4 pass-through) ran too slow.
168.85 The motor (tray 4 pass-through) ran too fast.
168.86 The motor (tray 4 pass-through) did not run at the
correct timing.
17y error messages
Error code Description Action
171.82 The main fan peed did not ramp up to the required
level.
See
“Main fan service check” on page 200.
171.83 The main fan stalled.
171.84 The main fan ran too slow.
171.85 The main fan ran too fast.
5028
Diagnostic information
176
