Lexmark CS720 - Page 338

9 Gently twist the rail to release the two tabs (D) from the frame, and then remove it.
D
Installation notes:
a Make sure that ITM dog bone retract (A) and the spring (B) on the new rail are securely attached.
A
B
5028
Repair information
338
