b When reinstalling the EP gear box, carefully insert the ITM drive shaft through the left side of the frame
and rail to avoid damaging the ITM dog bone retract.
c Make sure that the tabs (C) are properly inserted into the frame.
C
d Make sure to place the rail below the thermistor wire tie (D).
D
5028
Repair information
339
