2-58 Service Manual
4062
244.49 HCIT tray lift motor
stalled failure
Source = Tray 4
The HCIT tray lift motor has
stalled or has become
obstructed.
1. Ensure the HCIT media tray
assembly is properly inserted
into the machine.
2. Check the HCIT tray lift
motor assembly for binding or
damage.
3. Replace the HCIT tray lift
drive motor assembly if
problem remains.
Go to “High capacity input
tray (HCIT) tray lift drive
motor assembly removal” on
page 4-125.
244.50 HCIT tray lift motor
underspeed failure
Source = Tray 4
The HCIT tray lift motor does
not rotate at the specified
speed.
1. Ensure the HCIT media tray
assembly is properly inserted
into the machine.
2. Check the HCIT tray lift
motor assembly for binding or
damage.
3. Replace the HCIT tray lift
drive motor assembly if
problem remains.
Go to “High capacity input
tray (HCIT) tray lift drive
motor assembly removal” on
page 4-125.
244.52 HCIT tray lift motor
overrun failure
Source = Tray 4
The HCIT tray lift motor
continues to detect pulses after
the motor has turned off.
1. Ensure the HCIT media tray
assembly is properly inserted
into the machine.
2. Check the HCIT tray lift
motor assembly for binding or
damage.
3. Replace the HCIT tray lift
drive motor assembly if
problem remains.
Go to “High capacity input
tray (HCIT) tray lift drive
motor assembly removal” on
page 4-125.
Error
code or
message
Error contents Description/Action Possible repair actions
