Lime Microsystems LMS7002MR3 - Page 14

10
Address (15 bits)
Bits
Description
0x0021
15 – 12
11
10
9
8
7
6
5
4
3
2
1
0
Reserved
TX_CLK_PE: Pull up control of TX_CLK pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
RX_CLK_PE: Pull up control of RX_CLK pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SDA_PE: Pull up control of SDA pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SDA_DS: Driver strength of SDA pad.
0 – Driver strength is 4mA (default)
1 – Driver strength is 8mA
SCL_PE: Pull up control of SCL pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SCL_DS: Driver strength of SCL pad.
0 – Driver strength is 4mA (default)
1 – Driver strength is 8mA
SDIO_DS: Driver strength of SDIO pad.
0 – Driver strength is 4mA (default)
1 – Driver strength is 8mA
SDIO_PE: Pull up control of SDIO pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SDO_PE: Pull up control of SDO pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SCLK_PE: Pull up control of SCLK pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SEN_PE: Pull up control of SEN pad.
0 – Pull up disengaged
1 – Pull up engaged (default)
SPIMODE: SPI communication mode.
0 – 3 wire mode
1 – 4 wire mode (default)
Default: 00001110 10011111
