55
Address (15 bits)
Bits
Description
0x0096
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
BYP_LDO_AFE: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_CPGN: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_CPSXR: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_CPSXT: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIG: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIGGN: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIGSXR: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIGSXT: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIVGN: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIVSXR: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_DIVSXT: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_LNA12: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_LNA14: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_MXRFE: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_RBB: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
BYP_LDO_RXBUF: Bypass signal for the LDO
0 – Does not bypass. Normal LDO operation (default)
1 – Bypasses LDO. Connects Vinput to Voutput
Default: 00000000 00000000
