56
Address (15 bits)
Bits
Description
0x0097
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
SPDUP_LDO_DIVSXR: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_DIVSXT: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_LNA12: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_LNA14: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_MXRFE: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_RBB: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_RXBUF: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TBB: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TIA12: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TIA14: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TLOB: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TPAD: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_TXBUF: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_VCOGN: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_VCOSXR: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
SPDUP_LDO_VCOSXT: Short the noise filter resistor to speed up the settling time
0 – noise filter resistor in place (default)
1 – Noise filter resistor bypassed
should be connected to a 1~5uS at the power up
Default: 00000000 00000000
