58
Address (15 bits)
Bits
Description
0x009D
15 – 8
7 – 0
RDIV_RXBUF[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_TBB[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x009E
15 – 8
7 – 0
RDIV_MXRFE[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_RBB[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 140
Vout=860mV+3.92mV *RDIV
Default: 01100101 10001100
0x009F
15 – 8
7 – 0
RDIV_LNA12[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_LNA14[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 140
Vout=860mV+3.92mV *RDIV
Default: 01100101 10001100
0x00A0
15 – 8
7 – 0
RDIV_DIVSXR[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_DIVSXT[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x00A1
15 – 8
7 – 0
RDIV_DIGSXT[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_DIVGN[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x00A2
15 – 8
7 – 0
RDIV_DIGGN[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_DIGSXR[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x00A3
15 – 8
7 – 0
RDIV_CPSXT[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_DIG[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x00A4
15 – 8
7 – 0
RDIV_CPGN[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_CPSXR[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
0x00A5
15 – 8
7 – 0
RDIV_SPIBUF[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
RDIV_AFE[7:0]:Controls the output voltage of the LDO by setting the resistive
voltage divider ratio. Default: 101
Vout=860mV+3.92mV *RDIV
Default: 01100101 01100101
