4 Operation
Special equipment
Switch off the truck and log off:
¾ Rotate the turning knob (6) anticlockwise to
the stop.
The engine is turned off.
NOTE
After a delay time (factory setting = 10 se-
conds) the red LED (1) lights up briefly, and
the green (2) and red (1) LEDs then flash for
approx. 3 seconds. During this period, the
truck can be started at any time. The LEDs
then go out, and the PIN is discarded. The
delay time can be set to between 10 seconds
and 10 minutes using the diagnostic device.
Please contact your authorised dealer.
Pressing the
#
button (3) a
fter switching
off the engine terminate
s the delay time
immediately and the PIN i
s deleted.
Truck data acquisition
with a transponder
(chip or magnetic stri
pcard)
NOTE
The input device has a field (3) onto which the
corresponding transponder (chip or magnetic
strip card) must be placed. Only then can the
truck be started.
86 Operating Instructions – 394 807 10 01 EN – 07/2011
