LivaNova CP5 - Circuit board keys and LEDs

CP5 • System description
22 CP_SEM_60-00-60.001
Circuit board keys and LEDs
Fig. 5: Circuit board keys and LEDs
A 28
A 30
A 29
Item Name Number Part Number
A28 Circuit board keys and LEDs
(for registration of the shaft encoder with cable har-
ness; not shown here)
HKD 0327 90-305-640
A29 LED light guide, 7-element
A30 Contact pin to circuit board computer board A 5
