CP5 • Replacing components
CP_SEM_60-00-60.001 55
6.3 Replacing circuit boards/sensor module
As the exterior design of the sensor modules is virtually identical, we have only used one figure of the
interface module in following description. In the interest of clarity, cables and connectors have been
omitted. Always mark the plugs and cables to avoid mistakes in subsequent assembly.
!
Please note that it is essential that ESD protective safety measures are taken when working with
components susceptible to ESD. When removing or fitting circuit boards or components susceptible to
ESD, ensure that you use ESD mats, wrist straps, or similar.
Fig. 29: Replacing sensor boards (1)
◗ Remove the screws on the cover a and back b of the module.
