CP5 • Appendix
CP_SEM_60-00-60.001 67
7.6 Service component part numbers
These part numbers concern assemblies and components that are intended solely for use by service
technicians. The position number references relate to the illustration of the components in Chapter 3.
7.6.1 Pump control panel
Item Name Number Part Number
System socket side with cable harness 97-103-663
Connection cable control panel
<– –> E/P pack
97-102-628
Ribbon cable 8-conductor (for inverter) 96-231-042
Ribbon cable 33-conductor (for TFT display) 96-231-043
Pump control panel cable harness 97-101-935
Speaker cable harness, 280 mm 97-101-953
A 1 Housing (top) 75-521-515
A 2 Housing (bottom) 75-521-516
Front foil 76-102-964
EMC sealing cord 96-530-127
A 12 Toggle switch 1-pole Typ 1801 96-121-209
A 4 LCD touch screen with cable 97-103-616
Seal for LCD touch screen 72-102-028
Insulating film for LCD touch screen 72-102-074
A 11 Line filter FN332Z-10-05 96-401-012
A 16 Fan - SmartCooler LFX1460E 96-406-030
A 13 Speaker 96-413-012
A 14 Shaft encoder with cable harness 97-103-608
Nut for panel (setting knob) 10-85-13
A 15 Rotary knob 10-85-14
Rotary ring 75-521-529
Threaded rod, DIN 916, M4x6 71-118-317
Washer PA 6,2 x 12,0 x 0,5 71-120-514
Display carrier RP 10-85-15
