LivaNova CP5 - Drive unit and emergency system

CP5 • Appendix
68 CP_SEM_60-00-60.001
7.6.2 Drive unit and emergency system
A 5 Computer board HKR 0325 90-305-620
A 6 Keys and LEDs circuit board HKD 0327 90-305-640
A 7 Circuit board for fan control panel HDM 0503 90-305-850
A 8 Inverter (for LED display) LXM1617-05-6x 93-146-026
Inverter bracket 28-95-22
Socket head screw, DIN 912, M3x6 71-115-001
Socket head screw, DIN 912, M3x25 71-115-004
Socket head screw, DIN 912, M3x10 71-115-005
Socket head screw, DIN 912, M3x8 71-115-007
Socket head screw, DIN 912, M4x16 71-115-014
PT Screws K822x6 WN 1411 71-119-825
PT Z30x8 WN5411 71-119-830
Spring washer, DIN 127, B 3 71-120-526
Spring washer, DIN 127, B 4 71-120-527
Washer DIN 9021 3.2 71-120-601
Self-locking nut, DIN 985, M3 (WAF 5.5 mm) 71-121-527
Nylon washer M2.5 / OD=6 / T=0.5 93-920-026
Nylon washer M2.5 / OD=6.8 / T=1.1 93-920-029
Distance bolts 7.9/1.6/2.5 96-530-016
Item Name Number Part Number
B 9 Circuit board Motor control ZPR 0801 90-305-990
B 1 Connection cable pump control panel 97-102-612
Washer DIN 125 A 3.2 71-120-501
Spring washer, DIN 127, B 3 71-120-526
Socket head screw, DIN 912, M3x6 71-115-001
Fast clamp connector 43-42-60
Mast holder for emergency system with clamping
screw
60-01-52
Foil for emergency system 76-102-942
Cover for rod 76-102-942
