CP5 • Appendix
CP_SEM_60-00-60.001 63
7.2 Labelling
Icons on the pump control panel:
Icons on the sensor module:
Pressure display
Measurement and display range -200 to +800 mmHg
Resolution 1 mmHg
Accuracy of measured values ±5 mmHg
Emergency system
Speed display 7 LEDs
Resolution 500 rpm per LED (starting at 1000 rpm)
Speed display range 1000 to 4000 rpm
Accuracy ±250 rpm
Sensor module
Operating voltage +5 V (from DC/DC module)
24 V (system voltage)
Power consumption 3 W
– For switching the pump control panel and the
connected drive unit on/off
F1 Channel for connecting the flow sensor
Sensor module for flow measurement
