CP5 • Appendix
CP_SEM_60-00-60.001 61
7 Appendix
7.1 Technical specifications
7.1.1 Dimensions, weights, operating conditions
For further information on the technical specifications, please refer to the HLM operating instructions.
Pump control panel
Height 260 mm
Width 190 mm
Depth (without mast holder) 100 mm
Weight (with mast holder) 3.5 kg
Drive unit
Diameter 96 mm (without mast holder)
Height 135 mm
Weight 3.0 kg
Emergency system
Diameter of emergency system 100 mm (without mast holder)
Height 250 mm
Weight 3.5 kg
Height of hand crank 115 mm
Diameter of hand crank 26 mm
Operating conditions
Operating temperature +10°C … +40°C
Storage temperature 0°C … +40°C
Relative humidity (operation and storage) 30% … 75%
