CP5 • Fault messages and troubleshooting
CP_SEM_60-00-60.001 39
An internal malfunction has occured.
➜ (Possible) fault in the main processor of the circuit
board HKR 0325 (e.g. errors occur when saving or
reading values).
◗ Delete message in system menu (twice if necessary)
◗ Replace the circuit board HKR 0325, and send it to the
manufacturer
◗ where necessary, send pump to manufacturer for
checking
The CP5 cannot be operated with the current firmware version
of the respective device. In this case: the firmware version of
the Air Purge Control (APC), the pressure monitor and the
UPS.
◗ Update the firmware version
For further information, see inside front cover of the
separate operating instructions for the CP5 and the
respective overall system.
Contact your service technician.
Short-term internal malfunction,
remains operational - Centr.Pump 1
Centr.Pump 1:
APC module firmware not compatible
Centr.Pump 1: Pressure module
firmware not compatible
Centr.Pump 1: System module
firmware not compatible
Centr.Pump 1: Display module
firmware not compatible
The display of current flow rate and the current pump speed
may be missing or incorrect.
➜ Touch screen defective
➜ Fault in circuit board Computer board (HKR 0325)
◗ Replace touch screen
◗ Replace circuit board HKR 0325
The temperature of the pump head rises above the specified
set temperature. The pump head might transmit heat to the
blood in the tubing.
➜ Fan defective
➜ Fault in circuit board Computer board (HKR 0325)
➜ Fault in motor
◗ Check fan function (where necessary replace fan)
◗ Replace circuit board HKR 0325
◗ Replace motor
LED display on pump control panel remains dark.
➜ Connections to circuit board keys and LEDs
(HKD 0327) interrupted
➜ Fault in circuit board HKD 0327
➜ (possible) fault in circuit board HKR 0325
◗ Check connections to HKD 0327
◗ Replace circuit board HKR 0327
◗ where necessary replace circuit board HKR 0325
Graphic display failure
Pump 1
Excessiv internal temperature
Pump 1
Setting knob LED failure
Pump 1
