QUICK LOAD SERVO 80 S2
Auxiliary end of bar position (option)
Depending on the lathe and its interface, the auxiliary end of bar may
be used in several ways, for example, to control the opening and the
closing of an additional steady rest in the lathe. The setting is identical
to the End of bar signal.
Loading flag position
This parameter allows to adapt another loading flag, and set it s length
accordingly.
Loading of random / equal length bar stocks (option)
Selecting the equal length parameter allows the bar feeder to spare
time at the new bar loading.
When the bar stocks have an equal length and this parameter is
selected, the bar feeder measures the first bar length. The second bar
stock is no longer measured; the loading flag moves forward at high
rate to the rear of the bar stock, reducing the bar stock loading.
Loading with fixed spindle liner installed (option)
When a fixed spindle liner is installed in the spindle, a new bar stock
can be loaded during the machining of the current bar stock.
· The bar feeder positions the bar stock in the spindle liner and
waits for loading signal with the pusher already behind the
bar stock.
· Once the signal activated, the pusher positions the new bar
stock into the clamping device and pushes out the remnant.
· When the bar stock is in position, the cycle restarts.
AUXILIARY END OF
BAR POSITION:
[@@@@]MM
ESC ENTER
LOADING OF BAR STOCK
[@]
1:RANDOM LENGTH
2:EQUAL LENGTH
ESC ENTER
LOADING WITH FIXED
SPINDLE LINER
INSTALLED:
[@]
1:NO
2:YES
ESC ENTER
LOADING FLAG
POSITION:
[@@@@.@]MM
ESC ENTER
