LNS QUICK SIX - Page 58

Chapter 3: Procedures
QUICK SIX
3-7
Step 3: Remove the pusher by pulling it out of the rear support and gently sliding it out of the pusher support bushing.
Pusher
Rear su
pp
ort
Pusher support
bushin
g
Step 4: Loosen the 6mm bolt on the pusher flag and remove the pusher connector from the pusher.
Pusher connector
Loosen 6mm bolt
Step 5: Remove the pusher tips on both pushers (8mm and 15mm pushers).
Note: Do not completely remove the screw from the 15mm pusher tip. Loosen the screw just enough so that the tip pops
out.
15mm pusher
Remove tip
8mm pusher
Remove tip
Step 6: Cut both pushers at the EXACT same length on the mark made on the first pusher.
Step 7: Drill and tap the small diameter pusher.
