12
User Manual
precisely, to ease and speed up all calculations, which so far have been done manu-
ally. If connected to a positioning instrument, the chartplotter displays the current
position, the speed, and the heading of the boat and its Track. The user information
like Waypoints, Marks and Tracks can then be stored on a User C-CARD and can be
recalled at any time. On the screen are shown navigation data and cartographic in-
formation obtained from electronic charts of C-MAP C-CARD.
When the package containing the chartplotter is first opened, please check it
for the following contents (if any parts are missing contact the dealer the chartplot-
ter was purchased from):
• External quick disconnect bracket and I/O cable 1,5 mt/5.9"
• Chartplotter's protective cover
• Fuse 2 Amp. + fuseholder
• User Manual
Note ONLY FOR PANORAMIC 8 SUN
The package contains the following parts too: Flush mounting kit; Smart DGPS WAAS Receiver
with cable 15 mt/45 feet.
C-MAP C-CARD (cartography data cards) are available through your local
dealer. For additional information on C-MAP Cartography visit web site at www.c-
map.com.
1.2.1 SPECIFICATIONS
1.2.1.1 Main Characteristics
Recordable Individual points
• User Points : 500
• Type of User Points : 16
Routes
• Routes : 25
• Max User Points per Route : 100
Tracking
• Tracks : 2
• Points per Track : 1000
• Step by Distance : 0.01, 0.05, 0.1, 0.5, 1, 2, 5, 10 Nm
• Step by Time : 1, 5, 10, 30 Sec, 1, 5, 10 Min
Cartographic Functions
• Detailed Map by using C-MAP C-CARD
• Coordinates System (ddd mm ss, ddd mm.mm, ddd mm.mmm, UTM, OSGB, TD)
