103
User Manual
between even, odd or none, the Stop Bits between 1 or 2. Default settings are:
Port = Port 1, Baud Rate = 4800, Data Bits = 8, Parity = none, Stop Bits = 1.
Input Data Display
Allows the chartplotter to act as a computer terminal and display the incoming
data exactly as it received.
If the data displayed on the screen is unrecognizable, you may have selected the
wrong input parameters for your particular receiver. Check your receiver manual
to be sure that you have selected the proper interface format. If the screen is
blank, you may have a broken connection and no data is being received.
Use 'ZOOM IN' to stop (or continue after pause) data displaying, 'ENTER' to
show data in hex or ASCII mode (normal or small) and 'CLEAR' to exit.
6.6.5 MODEM TEST
To check the Modem connections. Press 'ENTER' to select the preferred
Port (Port 1 or Port 2
FOR
CHARTPLOTTER
WITH
INTERNAL
GPS
RECEIVER
, Port 1, Port
2 or Port 3
FOR
CHARTPLOTTER
WITH
EXTERNAL
GPS
RECEIVER
) related to the connec-
tions made, to the Port that the Modem C-COM is connected.
