Before You Begin
This chapter provides basic information to get you start using the chartplot-
ter; it will help you to become familiar with the chart display and the functions of
the controls before you start using the chartplotter.
2.1 THE KEYBOARD
The 'CONTRAST'/'BACKLIGHT'/'POWER' key
Press and hold for 1 second the right side of 'POWER' to turn the chartplot-
ter On. Press and hold the right side of 'POWER' down (once the chartplotter has
been turned On) for 3 seconds turns the chartplotter Off.
Press and immediately release the right side of 'POWER' to adjust the back-
light, press and immediately release the left side of 'POWER' to adjust the contrast
of the display.
The key
Press 'MENU' to select the Functions Menu.
The key
Place the cursor and press 'GO-TO' to set Target.
The key
Press 'PAGE' to select the configuration our wish among cartography and
text area in two different modes (text area on the right side or on the bottom line of
the screen, full screen if Target has been inserted or with partial information on
SOG), only cartography, Depth Graph 1/2 screen and 1/3 screen pages, GPS Data
page, Navigation Data page, Graphic Data page, Wind Data page.
The key
Press 'MODE' to set the Navigate mode (Home).
