User Manual
Note
This item is shown alternately to the selection of the output messages when to the related port is
connected a GPS identificable by the chart plotter.
Internal GPS O NLY F OR COMPACT 8 S UN
Enables (On) or disables (Off) the Internal GPS. The default setting is On.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "INTERNAL GPS" + 'ENTER'
Restart GPS
Restarts all GPS processes. Once executed, the message "Done" is shown.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "RESTART GPS" + 'ENTER'
Differential Correction Source
Allows setting what kind of Differential Correction will be used by the GPS be-
tween WAAS-EGNOS and RTCM (beacon correction). The default setting is WAAS-
EGNOS.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "DIFF CORRECTION SOURCE" + 'ENTER'
Navigation Speed
Allows setting the Navigation Speed among Low Speed, Medium Speed and High
Speed.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "NAVIGATION SPEED" + 'ENTER'
3.2.8.5 Send & Receive Marks/Routes
Sets the desired port used for transferring User Points and Routes functions:
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"SEND/REC ROUTES & MARKS" + 'ENTER' + "Port1/Port2" + 'ENTER'
3.2.8.6 C-Link
Selects the Master unit (Primary Station) or the Slave unit (Secondary Station):
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"C-LINK" + 'ENTER' + "Secondary Station/Primary Station" + 'ENTER'
3.2.8.7 Cable Wiring Page
Shows a window containing the inteface cable wiring. See Par. 6.3 and 6.4.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"CABLE WIRING" + 'ENTER'
