User Manual
- Value Added Data (Pictures and Diagrams, Land Data)
- Enhanced Port Info
New Presentation Features
- Clear View (advanced legibility techniques providing more chart data on the screen)
- Clear Info (sophisticated "Human Dictionary" to translate Nav-Aid abbreviations
found on paper charts)
- Dynamic Fonts and Symbols
- Dynamic Nav-Aids (an innovative and dynamic presentation mode)
- Flexi-Zoom (increased Under and Over Zoom between chart levels, resulting in
optimal scale display for any situation)
- Dynamic Elevation Data (optimized palettes for chart plotters with 256 or more
colors; includes new NOAA palette for US market)
- Perspective View ("Real World" perspective view of the chart, updated real-time
during navigation)
MAX and NT/NT
+
C-CARD coexistence
- When NT
+
data and MAX data cover different areas, the chart plotter gets data
from both charts (depending on the current position).
- When NT
+
data and MAX data cover the same area, the chart plotter gets data only
from MAX chart.
3.5.1 MAP MENU
It is possible to select the Map Menu following the procedure:
'MENU' + "MAP SETTINGS" +'ENTER'
3.5.1.1 Perspective View
'MENU' + "MAP SETTINGS" +'ENTER' + "Perspective View" + 'ENTER'
Chart data may be projected in perspective mode during navigation. This
function allows setting the panoramic View of the chart.
As the upper side of the map is more compressed than the lower side, a wider map
area is visible. The perspective view allows showing more chart information immedi-
ately ahead and around the cursor.
