90
User Manual
Turns ON or OFF the alarm. The default setting is ON.
5.7.2.6 TCPA Limit
'MENU' + "AIS SETUP" + 'ENTER' + "TCPA LIMIT" + 'ENTER'
The values allowed are from 1 to 30 min. The default setting is 10 min.
5.7.3 TO SET THE CHART PLOTTER FOR RECEIVING AIS
Make sure that the AIS receiver is properly connected to the chart plotter.
The chart plotter reads the AIS NMEA message VMD, type 1, 2, 3 and 5.
Select the used serial port and transmission speed by following the proce-
dure:
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"PORT n INPUT" + 'ENTER' + "m" + 'ENTER'
Where: n = Port 1/Port 2/Port 3
m = NMEA-0183 4800-N81-N
NMEA-0183 38400-N81-N
according to the transmission speed of your AIS receiver.
5.7.4 QUICK INFO ON AIS TARGET
By placing the cursor over a AIS target icon, the following information is
displayed:
• Vessel Name
• MMSI number
• Radio Call Sign
• SOG
• COG
• CPA and TCPA values
Note
The selected AIS target icon is surrounded by a square frame when user places the cursor over the icon.
5.8 C-STAFF
The C-Staff functions are based on STAFF Concept ® (Satellite Tracking
Aided Fleet Fishing). The STAFF Concept ® is designed for professional fishing
purpose to allow monitoring the position of the vessels of a fleet from each vessel
(the fleet may have until 20 vessels max).
