70
User Manual
4.3.5 INSERTING THE A-B-C-D POINTS
Placing cursor on the segment connecting two points, the information win-
dow appears. Select "INSERT" and press 'ENTER': by the cursor key move the
cursor, on the screen a dotted line appears. By pressing 'ENTER' the new point is
placing between the two existed points which are renamed.
4.3.6 NAVIGATING ON THE A-B-C-D POINTS
If fix received is good, place the cursor on the desired point A, B, C or D and
press 'GO-TO'. When ship reaches the Destination point, navigation follows the
next point (if exists). When Target is set, three options are available: STOP NAV,
NEXT and PREV.
4.4 USING THE TRACK FUNCTIONS
As long as the chartplotter is connected to a positioning instrument, it stores
all points in its memory. The chartplotter can store a fix when the distance from its
last stored position is greater than a defined distance or after a defined time. A line
connects such points and represents the past course, called the track of the ship.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER'
4.4.1 SELECTING ACTIVE TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' +
"ACTIVE TRK" + 'ENTER'
Select the number of the active track. The default setting is 1.
4.4.2 ENABLING TRACK STORING
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' +
"TRACCIA" + 'ENTER'
To enable (On) or disable (Off) the track storing. It is not possible to use the
track storing if you are not receiving a valid fix. The default setting is On.
4.4.3 DISPLAYING TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' +
"VISIBILE" + 'ENTER'
To enable (On) or disable (Off) the displaying of track. The default setting is On.
