5 -16
▶ The contaminated oil may reduce the durability of transmission and cause the
failure of hydraulic system. Clean around oil filling inlet and then open the cap.
Caution
(5) Battery check
z Refer to “Batter handling and Notices” (See page 5-38 )
(6) Air cleaner (Dry type)
z (See page 5-11 )
(4) Checking Front axle oil
z Open the oil check port plug and be sure to
check if the oil flows out.
z If necessary, add new oil into the oil filling inlet.
(after 5~10 minutes later, check the oil level
again)
z For oil specification, see section 5-3, “Lubricants
and Capacity” or the last page in this manual.
Oil filling inlet
Oil check port
(3) Checking Transmission oil
z Stop the tractor on level surface and apply the
parking brake and lower implements to the
ground.
z Clean around oil filling inlet and pull the gauge
straight out.
z If oil level is between “Min” and “Max” mark of oil
gauge, it means proper amount.
z For oil specification, see section 5-3, “Lubricants
and Capacity” or the last page in this manual.
Oil check inlet
To Next Page
