5 -35
▶ If the same function fuse is damaged repeatedly, contact your authorized local
dealer for check instead of using the alternatives such as wire or aluminum foil.
▶ If using the alternatives instead of the rated capacity fuse, it may cause fire which
results in the damage of tractor or injury.
Notice
① Cabin fuse box
z Cabin fuse box is installed on the left cabin filler.
z How to replace the fuse
1. Remove the cover of fuse box.
2. Check each fuse and remove the damaged fuse.
3. Replace the new one same as damaged one.
z Capacity and function of each fuse is described
in the cover of fuse box.
< Fuse box in the cabin (Cabin type) >
(4) Fuse & Main fuse
Cabin fuse box cover
② Chassis fuse box
z Chassis fuse box is installed under the front
console cover.
z How to replace the fuse
1. Remove the cover of fuse box.
2. Check each fuse and remove the damaged fuse.
3. Replace the new one same as damaged one.
Chassis fuse box
