3 -28
(2) Creeper gear lever (if fitted)
z If you pull the lever upward for creeper speed
range, and push it down for standard speed
range.
z If the range gear shift lever is in “H” position, it is
not possible to shift to the creeper speed range.
After changing the range gear shift lever to “L” or
“M” position, operate the creeper gear lever.
▶As the driving force of rear axle is very high in creeper speed range, the tractor may
not be stopped even if pressing brake pedals. In this case, press the clutch pedal
together with pressing brake pedals.
Caution
Creeper gear
lever
Creeper range
Standard range
▶After placing PTO switch in
“OFF” and PTO shaft has
stopped completely, place the
lever to desired position.
▶If the PTO gear lever is NOT
engaged smoothly, lift up/down
the implement to align drive
shaft.
Caution
(3) PTO gear lever
z 540 / 750 / 1000 rev/min and neutral position are
available.
(4) GSP lever
z If you pull the lever up, the ground speed PTO
(GSP) is engaged.
z If you push the lever down fully, the ground
speed PTO (GSP) is disengaged and
independent PTO is engaged.
z Depress clutch pedal and stop the tractor
completely and then operate the GSP lever.
GSP lever
1000rpm
750rpm
540rpm
Neutral
GSP PTO
Independent PTO
PTO gear lever
