5 -24
(5) Checking Nozzle injection pressure
z Contact your authorized local dealer for check.
Normal injection pressure : 180 MPa (26107 psi)
(6) Replacing Cabin air filters
z Before servicing the filters, switch off the blower
and close all cabin doors and windows.
z Unscrew the bolts under the roof and remove
the cover and filter element as shown in the right
figure.
z Clean both filter chambers with a damp, lint-free
cloth.
z Replace the cabin air filters with a new one.
z Re-install the filter cover and tighten the bolts.
▶ The filters are made of specially treated media with a rubber sealing strip bonded
around the sides. Take care not to damage the element during installation.
Notice
Cabin
air filter
Bolt
Filter cover
