3 -21
Power out socket
(5) Electrical power outlet socket (Cabin type)
Caution
▶ When using a cigarette lighter jack, cares must be taken not to touch the heating
coil. The heat generated coil is very hot and may cause the danger of a burn.
(7) Audio player (Cabin type)
z Refer to the attached user’s manual of audio player.
▶To ensure safe operation, avoid turning up the player volume so high/loud.
▶Do not use a headset while driving tractor.
Caution
(6) Indoor light (Cabin type)
z Press the lower side of indoor light to turn on the
light.
z Press the lower side of indoor light again to turn
off the light.
Indoor light
z This is used to withdraw the electric power for
charging of the cigarette lighter jack or cellular
phone.
z In case of using cigarette lighter jack (optional),
If pushing the cigarette lighter jack into the
socket, the heated coil can be used as an
alternative of lighter.
z In case of using as power supply (12V), use the
cellular phone charger less 10A.
