3 -13
▶As soon as engine starts, turn the ignition key to ON position immediately. If not, it
may cause damage to starter motor.
▶If the tractor is not in use, the ignition key should be removed.
Caution
(2) Key switch
z “OFF” – power off (engine stop)
z “ON” – power on
z “START” – engine start
Key switch
OFF
ON
START
(3) Throttle pedal
z This pedal is used when driving on road.
z When using the throttle pedal, the throttle lever
must be placed in “Low speed”.
z When pressing brake pedals with pressing the
throttle pedal first, the engine speed shall be
changed to low idle.
z When pressing the throttle pedal with pressing
brake pedals first, the engine speed shall be
controlled by throttle pedal.
z There is a sensitive electric sensor on the
throttle pedal. Do not remove or modify the
throttle pedal arbitrarily.
Throttle pedal
Brake pedals
