3 -24
z The engine starts only when PTO switch is
placed in OFF position for safety.
z After starting the engine, you must comply with
the operation procedure of the PTO switch as
follow.
1. Place the PTO gear lever to desired position.
2. Select the PTO mode switch to “AUTO” or
“Manual” position.
3. Pull the PTO switch with pressing the lock
button of the switch to engage the PTO.
The PTO operation indicator shall be ON .
4. If you want to stop the PTO temporarily while
operating, push the PTO switch in OFF position.
The PTO shaft shall be stopped.
(12) PTO switch
PTO switch
▶ Before attaching or checking the PTO driven equipment,
- Always place the PTO switch in OFF position, and PTO gear lever in NEUTRAL
position.
▶ If the PTO mode switch is placed in MANUAL position, PTO shall rotate always
even if the tractor moves backward. Pay attention to the surroundings to prevent a
accident.
▶ Do not engage the PTO clutch at high engine speed. Sudden engagement can
cause damage to implements and tractor.
Engage PTO at low engine speed, and then raise engine speed to rated RPM.
Warning
OFF
ON
PTO mode switch
