8 -4
XP8084 XP8094 XP8101
Differential lock
Electro-Hydraulic Differential lock (EHD)
PTO
Type Independent PTO with wet disk clutch
No. of speed 3 speed gears (optional)
PTO / Engine
1
st
speed : 540 rpm / 1958 rpm
2
nd
speed : 750 rpm / 2132 rpm
3
rd
speed : 1000 rpm / 2125 rpm
HYDRAULIC LIFT
3 Point linkage CAT 2
Draft load detection Upper link
Lowering speed
control and cylinder
fixing device
Down speed control valve
Pump Gear pump type, Engine drive
Rated flow 59.4LPM (15.7 gpm)
System pressure 18.6MPa (2702psi)
Lift
capacity
Lower link
end
3290 kgf
(7253 lbf)
24” behind
lift point
2350 kgf
(5181 lbf)
REMOTE
CONTROL
Type Double acting (Spring return type / Detent type(optional))
No. of Q/coupler SAE ½”, 4~6EA (optional)
F/Loader coupler Front outlet valve / Joystick loader valve (optional)
STEERING SYSTEM
Type Hydrostatic
Oil Transmission oil (common use)
Min. turning radius
(with brake)
3.5m (11.5ft)
Max. steering angle
53°
No. of steering turns 4.0 turns from stop to stop (maximum)
Rated flow / pressure 24.8LPM (6.5 gpm) / 14.2MPa (2060 psi)
