LS tractor XP8084 - PTO Mode Switch (if Fitted)

3 -38
 It is used to select “AUTO” or “'MANUAL” mode
of the PTO operation
 When the PTO mode switch is placed on
- AUTO: if pressing the clutch pedal or lifting up
the position control lever over the specified
position, the PTO will be stopped.
- MANUAL: The PTO shaft will rotate always
regardless of the clutch pedal or position control
lever.
(10) PTO mode switch (if fitted)
PTO switch
PTO mode switch
Cabin
PTO mode switch
Roll-bar
