LS tractor XP8084 - Combination Light Switch

3 -18
▶ When passing with other vehicles in the opposite lane at night, turn the headlights
to low beam not to disturb oncoming cars.
Caution
Combination light switch
ON
- Instrument light and all lights are OFF.
- Instrument light, side lights and tail
lights are turned on.
- Instrument light, side lights and tail
lights and headlights(Low beam) are
turned on.
 To turn on/off the lights described as below, turn
the switch to the position where the related
symbol is marked.
2
4
1
3
3
CabinRoll-bar
Cabin
2
4
Roll-bar
(7) Combination light switch
1
Turning ON/OFF the lights
 Combination light switch is used to turn on/off the following lights.
① Instrument panel lights. ② Side lights. ③ Tail lights. ④ Headlights.
