LS tractor XP8084 - Engine Speed Cruise Control(ESC) Switch

3 -40
ESC main switch
ESC main switch
Engine ESC speed
(12) Engine Speed Cruise control(ESC) switch
① ESC main switch
 This switch is used to enable the Engine Speed
Cruise control(ESC) function.
 If pressing the ESC main switch from position 0
to position 1 (Off –> Ready),
- ESC indicator on the instrument panel will be
blinked.
- Engine speed stored on ECU will be displayed
on LCD panel.
 If pressing the ESC main switch from position 1
to position 2 (Ready –> Resume),
① (if pressing below 2 second) – ESC
indicator will be ON and engine speed cruise
control(ESC) will begin.
② (if pressing over 2 second) – current engine
speed will be stored on ECU and the stored
engine speed will blink 3 times on LCD panel.
 To exit the ESC control,
-. Press the lower side (“Off ”) of the ESC main
switch or press down the brake pedals.
Cabin
• Position 2 : Resume
• Position 1 : Ready
• Position 0 : Off
ESC main switch
Roll-bar
ESC main switch
