3 -15
▶DO NOT ride your foot on the clutch pedal while driving the tractor.
▶As the start safety switch is installed for the operator’s safety, depress the clutch
pedal fully to start engine.
Caution
(4) Clutch pedal (MEC models
only)
 This is used to engage or disengage the main
transmission clutch for starting engine and
shifting transmission gear.
 Depress the clutch pedal quickly and fully and
release it slowly.
 If the PTO mode switch is placed on “Manual”,
the PTO shaft will NOT stop, if the switch is
placed on “AUTO”, the PTO shaft will be
stopped, when depressing the clutch pedal.
Clutch pedal
