5 -30
(1) Lubricating grease nipple
Front axle front/hear holders
Front axle king-pin shaft cover (lower)
3-point linkage
5-7. Every 50 hour check
Grease nipples
(2) Cleaning Radiator and Radiator screen
See chapter 5-6-(7) in this manual. (See page 5-26)
Grease nipples
Grease nipple
(Both side)
Grease nipple
1.Wipe dirt from fittings before greasing.
2.Use a grease gun containing clean high grade of
grease.
For grease specification, see chapter 5-3,
“Lubricants and Capacity” or the last page in this
manual.
3.Pump fresh grease into fitting to adequately
lubricate the component and force out any
contamination from the grease passage.
4.Wipe off excess grease.
To Next Page
