3 -24
Cabin
(11) 4WD switch
Press the upper side (symbol part) of the switch
to engage the Four wheel drive.(4WD)
Press the lower side of the switch for 2WD.
Front wheel drive (4WD) is effective for the
followings.
-When traction is needed in plow ground.
-When working on slippery ground.
-When working with tiller on hard ground.
-When crossing a ridge
▶ When driving on public roads, disengage the 4WD. If not, it may cause damage of
the drive line and a serious accident. After working, before coming out from the field,
disengage the 4WD.
▶ When driving the tractor at high speed while the 4WD engaged, sharp steering
may cause an accident.
Caution
4WD switch
Roll-bar
4WD switch
